MERKMALE

LFP Cells. Cobalt Free

LFP Cells. Cobalt Free

Floor Mounted

Floor Mounted

The Battery Is More Integrated And Lighter

The Battery Is More Integrated And Lighter

Metal Case And Tiny Size

Metal Case And Tiny Size

Fast Charge And Discharge. No Memory Effect

Fast Charge And Discharge. No Memory Effect

Match With Mainstream Inverter Brands

Match With Mainstream Inverter Brands

SPEZIFIKATION


Battery Data

Rated Voltage

51.2V

Rated Energy

15.46kWh

Cell Capacity

302Ah

Discharging Voltage

45~54V

Charging Voltage

51.5V~54V

Operating Temperature

0℃ ~ 45℃ (Charge)

-20℃ ~ 45℃ (Discharge)

Cont. Charging Current

200A

Peak Charging Current

230A

Cont. Discharging Current

200A

Peak .Discharging Current

230A

Rated. Discharging  Power

10000W

Max.Discharging DC Power

5000W More than 2 units


General Data

IP Grade

IP31

Scalability

Up To 4 Units

DOD

90%

Installation

Floor mount

Dimension

980×460×230mm

Weight

120kg

Authentication

UN CE

Compatible Inverter

GoodWe/Deye/Megarevo/Growatt/Lux Power/TBB/Victron/Srne/Must/Senergy/Voltronic/Aptai/Sofar/Sma,etc
