| Battery data | |
| Rated voltage | 51.2V |
| Rated energy | 30.05kWh |
| Nominal capacity | 587Ah |
| Discharge Voltage | 44.8V |
| Charge voltage | 58.4V |
| Operating temperature | 0℃~55℃（Charge） -30℃~55℃（Discharge） |
| Continuous charge current | 150A |
| Peak charge current | 150A |
| Continuous discharge current | 150A |
| Peak discharge current | 300A |
| Max. Continuous DC Power | 15000W |
| General data | |
| IP protection level | IP21 |
| Extensibility | Supports parallel connection of up to 15 units. |
| DOD | 90% |
| Lnstallation method | floor standing |
| Cycle life | >6000 |
| Communication protocol | RS485 / CAN2.0 |
| Demension | 665*310*990mm |
| Warranty | 5 Years |
UN38.3、CE、IEC62619
* When the temperature is below 0 ℃ or above 45℃, the performance will be limited.
