MERKMALE

From 5.12 kWh to 30.6 kWh

From 5.12 kWh to 30.6 kWh

Automatically set matching voltage

Automatically set matching voltage

IP65, Support for outdoor use

IP65, Support for outdoor use

Wireless connection/easy installation/more space saving

Wireless connection/easy installation/more space saving

Use lithium iron phosphate battery cells

Use lithium iron phosphate battery cells

Matching with mainstream inverter brands

Matching with mainstream inverter brands

SPEZIFIKATION

Model

LV M05

LV M10

LV M15

LV M20

LV M25

LV M30

Number of modules

1

2

3

4

5

6

Nominal capacity

100Ah

200Ah

300Ah

400Ah

500Ah

600Ah

Nominal battery energy

5.12kWh

10.2kWh

15.3kWh

20.4kWh

25.5kWh

30.6kWh

Maximum continuous discharge power

5kW

10kW

10kW

10kW

10kW

10kW

Maximum continuous charge power

5kW

10kW

10kW

10kW

10kW

10kW

Dimension[W*D*H](mm)

700*370*441

700*370*609

700*370*777

700*370*945

700*370*1113

700*370*1281

Weight

73.7kg

123.2kg

172.7kg

222.2kg

271.7kg

321.2kg

Operating temperature

0℃~50℃(Charge) -20℃~55℃ (Discharge)

Provide warranty documents

Yes

IP protection level

IP65

Colour

White

Warn

Over charge / Over discharge / Over current / Overheating / Short circuit

Advantage

Can be used for off grid and hybrid settings, compact design, modular expansion

Battery module type

Low voltage

Connection mode

Paralleling

Authentication

UN CE ,IEC

Compatible inverter

GoodWe/Deye/Megarevo/Growatt/Lux power/TBB/Victron/Srne/Must/Senergy/Voltronic /Aotai/Sofar/Sma, etc.

Communication protocol

RS485/CAN
