Item | LV U05 | LV U10 | LV U15 | LV U20 | LV U25 | LV U30 |
Module Number | 1 | 2 | 3 | 4 | 5 | 6 |
Nominal Capacity | 100Ah | 200Ah | 300Ah | 400Ah | 500Ah | 600Ah |
Nominal Battery Energy | 5.12kWh | 10.2kWh | 15.3kWh | 20.4kWh | 25.5kWh | 30.6kWh |
Max. Discharge Power | 5kW | 10kW | 10kW | 10kW | 10kW | 10kW |
Max. Charge Power | 5kW | 10kW | 10kW | 10kW | 10kW | 10kW |
Dimension[W*D*H] | Defined by the cabinet dimensions | |||||
NetWeight | 45kg | 90kg | 135kg | 182kg | 225kg | 270kg |
Temp.Range | 0℃ ~ 50℃（Charge） -20℃ ~ 55℃ （Discharge） | |||||
Warranty Letter | Yes | |||||
Ingress Protection | IP21 | |||||
Color | BLACK | |||||
Alarms | Over Charge / Over Discharge / Over Current / Over Temperature / Short Circuit | |||||
Pros | Can be used in both off-grid and hybrid set ups, compact design | |||||
Battery Module Type | Low Voltage | |||||
Module Connection Method | Parallel | |||||
Compatible Inverters | GoodWe/Deye/Megarevo/Growatt/Lux Power/TBB/Victron/Srne/Must/Senergy/Voltronic/Aptai/Sofar/Sma,etc | |||||
LV U Series
Cell Capacity: 100Ah
Nominal Battery Energy：5.12~30.6kWh
Warranty : 10 years
Cycle Life : 6000/times
DOD : 90%
Nominal Voltage : 51.2V
Cell Type: LFP CATL
