MERKMALE

Container can be quickly deployed. Easy for transport and install. can lowered the infrastructure and construction cost and shorten the construction time.

Container can be quickly deployed. Easy for transport and install. can lowered the infrastructure and construction cost and shorten the construction time.

The container can be paired the with photovoltaic farm. wind turbine farm. electric grid etc. It is a large multi-function smart energy storage station.

The container can be paired the with photovoltaic farm. wind turbine farm. electric grid etc. It is a large multi-function smart energy storage station.

Comprehensive and multi-level battery protection strategies and troubleshooting measures are in place.

Comprehensive and multi-level battery protection strategies and troubleshooting measures are in place.

Various units can be easily combined together to satisfy the electricity needed by your business.

Various units can be easily combined together to satisfy the electricity needed by your business.

SPEZIFIKATION

Modle

N-BES-500kW/1000kWhN-BES-1000kW/2000kWh

DC Data



Cell Type

 LFP                                                            LFP

LFP                                                            LFP

Cell CYcle Life

6,000 Cycles                                              10,000 Cycles

6,000 Cycles                                             10,000 Cycles

CeLL Specifications

3.2V/280Ah                                               3.2V/314Ah3.2V/280Ah                                              3.2V/314Ah

Configuration

1P224S                                                      1P224S

1P224S                                                    1P224S

Number of Bettery Clusters

5                                                                5

10                                                            10

Rated Power

1003.52kWh                                             1125.37kWh

2007.04kWh                                            2250.75kWh

Rated Voltage

716.8V                                                      716.8V

716.8V                                                     716.8V

Voltage Range

627.2V~817.6V                                        627.2V~817.6V

627.2V~817.6V                                       627.2V~817.6V



AC Data


Rated Power

500kW                                                     500kW

1000kW                                                    1000kW

Rated Voltage

400V                                                        400V

400V                                                         400V

Rated Current

722A                                                        722A

1444A                                                       1444A

Output THDi

<3%                                                      <3%

<3%                                                       <3%

Communication  PF

0.1~1 Lead or lag (configurable)

0.1~1 Lead or lag (configurable)

AC Output

three-phase four-wire+PE

three-phase four-wire+PE

Universal Data


Size (W*D*H)

6,058x2,438x2,591mm

1219x2,438x2,591mm

Weight

≥20t

≥40t

IP

IP54

IP54

Working Temperature

-20~40℃

-20~40℃

Relative Humidity

0~95%

0~95%

Maximum Working Altitude

>2000m

>2000m

Cooling Mode

Air Cooling

Air Cooling
